Infisense® FS256Pro Fever Screening Security System For Facility Security OEM Sale
Infisense® FS256Pro Fever Screening Security System For Facility Security OEM Sale
Couldn't load pickup availability
Infisense® FS256Pro:
Infisense® FS256Pro Fever Screening System adopts infrared radiation measurement technique to measure body temperature by non-contact means. It provides audio alarrr and visible image capture when a person with elevated temperature passes by.
Suitable for public places with large flows of people, such as airports, transportation hubs, shopping malls, schools, enterprises.
Features
- Intelligent measure algorithm
- Identity recognition
- Quick installing, easy operating
- For orderly flow scenes
- Recording and searching
- Auto audio alarm
Specification
|
Infisense FS256 Pro Automatic Double-light Human Body Thermometer |
||
|
Product model |
FS256PRO |
|
|
Infrared part |
||
|
Resolution |
256*192 |
|
|
Pixel size |
12μm |
|
|
NTED |
≤50mK |
|
|
Frame rate |
25hz |
|
|
Focal length |
3.2mm |
|
|
Field angle |
56°*42° |
|
|
F# |
1.1 |
|
|
Visible part |
||
|
Resolution |
1280*720 |
|
|
Field angle |
FOV 80° |
|
|
Focal length |
4.4mm |
|
|
Accuracy of temperature measurement |
||
|
Measuring range |
30~45℃ |
|
|
Accuracy of measuring temperature |
±0.5℃ (Environment temperature 10℃~40℃) |
|
|
Temperature measurement range |
≤4m |
|
|
Machine interface |
||
|
Machine interface |
HDMI |
|
|
Power |
||
|
Power input |
AC100-240V 50/60Hz 0.5A |
|
|
Power output |
DC5V 3A |
|
|
Software function |
||
|
High temperature alarm |
High-temperature alarm and image capture |
|
|
File export |
Support history inquiry, screening and export to local disk |
|
|
Live preview |
Live preview of visible and infrared image |
|
|
Face recognition |
Intelligent face recognition and tracking |
|
|
Parameter setting |
Pseudo-color selection, alarm, language and correction value setting |
|
|
Environmental suitability |
||
|
Working temperature |
10~50℃ (Environment temperature 10~40℃ accurate temperature measurement) |
|
|
Storage temperature |
-20~60℃ |
|
|
Packing specification |
||
|
Machine head size |
190mm*110mm*100mm |
|
|
Packing size |
394*194*153mm |
|
|
Net weight |
1420g (the actual shipment shall prevail) |
|
|
Gross weight |
1784g (the actual shipment shall prevail) |
|
|
Tripod size |
Folding size: 540mm Unfold height: 1560mm |
|
|
Assembly List |
||
|
Double-light tube machine*1 Power adapter (5V 3A)*1 Centrally-controlling machine*1 Centrally-controlling machine remote control*1 HDMI cable*1 Tripod screw*1 L type wrench *1 Tripod* 1(optional) |
||
Case Pictures
