Technical Parameter
|
|
Rated Power
|
≤1.2KW
|
|
Rated Temperature
|
1650℃，long time working temperature≤1600℃（Tungsten wire heating with vacuum degree＜10Pa）
|
|
Working Heat Station Temperature
|
φ50mm
|
|
Vacuum observation window
|
φ27mm
|
|
Heating station material
|
High purity boron nitride
|
|
Heater
|
Tungsten wear heater
|
|
Temperature measurement
|
B Type Thermocouple
|
|
Cold limit vacuum
|
Mechanical pump≤5Pa Cold State, Molecular pump 1 x 10-3Pa
|
|
Power
|
AC 220V 50Hz
|
|
Temperature controller
|
30 segment digital display temperature program controller+ Power regulator+ Temperature over limit alarm/current voltage feedback
|
|
Controller accuracy
|
±1℃
|
|
Heating rate
|
≤30℃/min
|
|
Enclosure spec
|
|
Vacuum chamber
|
Material SUS304,forced air cooling outside
|
|
Vacuum connector
|
Vacuum pumping connectorKF25,air inlet 6mm quick tighten, venting 8mm
|
|
Heating and Thermo insulation
|
Heating: Tungsten sheet, outside thermo insulated with Alumina thermal insulation material+Molybdenum foil+SUS insulation cover
|
|
Door cooling
|
SUS 2 layer water cooling
|
|
Temperature controller enclosure
|
Ordinary carbon steel+ spray treatment
|
|
Standard accessories
|
KF25 Vacuum flapper valve 1x,KF16 Inlet valve with pressure gauge 1x,KF16 Air outlet valve 1x,KF25 Thermocouple 1x,KF16 Clamp 2x,KF25 clamp 2x, Teflon tube 6m
|
|
Optional accessories
|
Digital vacuum gauge(with 3-way adapter),mechanical vacuum pump(with KF25 corrugated pipe) 1x, Water cooler(Teflon tube 6m),molecular pump(KF25 corrugated pipe 1x
|
