Specifications
Inspection Camera is appropriated for use in Surveying pipes, hard to reach areas, equipments, furnishing installation, car repairing, scientific study and diangostics, etc.
Allows for an easy visual inspection of hard-to-reach areas. Lightweight, handheld design for easily finding, dagnosing & solving problems with flexible extended tube, useful accessories, and a detachable/moutable monitor with recording capabilites.
GL8811:
FEATURES:
- A unique way of winding facilitates users operation
- 3" LCD screen makes it clearer for users
- Video snapshooting help users not miss anything
- Pic-in-Pic function is easy to diagnose any faults
- High-quality CMOS sensor resolution is 640x480 pixels
- Optical lens view angle is 45°
- Mini 8mm waterproof camera with flexible extended tube
- Manufactured and tested to IP67 waterproof standard
- 3 feet flexible extended tube allows for easy surveying of small and hard-to-reach places
- 4 AA batteries for power supply
- Camera head equips with these accessories including magnetic tip, mirror tip and hook.
GL8898:
FEATURES:
- Video out function for viewing in big screen
- Image flip function to view in different angles
- Light weight compact design to easily find, diagnose and solve problem
- Adjustable brightness on led-mounted LED right
- 4" TFT-LCD color monitor, brightness adjustable
- Mini 8mm waterproof camera with flexible extended tube
- Manufactured and tested to IP67 waterproof standard
- 4 AA batteries for power supply
GL9018:
FEATURES:
- Video out function for viewing in big screen
- Image flip function to view in different angles
- Light weight compact design to easily find, diagnose and solve problem
- Adjustable brightness on led-mounted LED right
- 4" TFT-LCD color monitor, brightness adjustable
- Mini 8mm waterproof camera with flexible extended tube
- Manufactured and tested to IP67 waterproof standard
- 4 AA batteries for power supply
GL8838:
FEATURES
- Display: 2.8" TFT-LCD,resolution 240(RGB)*320
- Camera:1/10 inch CMOS camera,resolution 640x480
- Brightness of the Display is adjustable(10 different adjustmen
- LED: 6x LED with white light,adjustable(10 different adjustmen
- Camera head diameter: 8mm
- About 100pcs photos onto internal memory
- Micro USB port, connect to the computer to see images
- Zoom steps: x1.5, x2, x3, x4
- Total length(mounted and including camera head): 100cm Video system
- IP67 for the camera head and tube
- Power: 4xAA battery swith these accessories including magnetic tip, mirror tip and hook
Specification
GL8811:
Items:Specifications
Diameter Of Camera Head:φ8mm
Image Sensor:CMOS
Effective Pixel:640*480pixels
Horizontal Viewing Angle:42±5°
Waterproof Level:IP67
Display Size:4.3" TFT LCD monitor
Screen Resolution:480(RGB)*272
Image Zoom:2x variable digital zoom
Photo Format:JPG
Interface Micro:USB
Power Supply:4AA Batteries
Power consumption:320mA（MAX）
Operation Temperature:–10～+50℃
Accessories:magnetic tip, mirror tip, hook and rubber ring
Product Size:180*109*65MM
Packing Size:30pcs/carton, 350*380*350mm
Weight(kg):14.1kg
GL8898:
Items:Specifications
Imaging sensor:CMOS
Total pixels:640 x 480
View angle:48º
Minimum illumination：0Lux (LED on)
Power supply：4×AA batteries
Tube diameter：8mm
Waterproof capacity：IP67 (Only for imager head)
LCD screen type：2.4" TFT-LCD
LCD screen effective pixels：960×240
Video system：PAL/NTSC
Consumption current：238±5mA/6V (Max.)
Operating temperature：-10OC~50OC/14OF~122OF
Operating humidity:15~85%RH (Max.)
Accessories:magnetic tip, mirror tip, hook and rubber ring
Product Size:320×204×64mm
Packing Size:5pcs/carton, 340*335*225mm
Weight(kg):5.5kg
GL9018:
Items：Specifications
Imaging sensor：CMOS
Total pixels：640 x 480
View angle：48º
Minimum illumination：0Lux (LED on)
Power supply：4×AA batteries
Tube diameter：8mm
Waterproof capacity：IP67 (Only for imager head)
LCD screen type：2.4" TFT-LCD
LCD screen effective pixels：960×240
Video system：PAL/NTSC
Consumption ：2W (Max.)
Operating temperature：-10OC~50OC/14OF~122OF
Operating humidity:15~85%RH (Max.)
Accessories:magnetic tip, mirror tip, hook and rubber ring
Product Size:320×204×64mm
Packing Size:5pcs/carton, 340*335*225mm
Weight(kg):5kg
GL8838:
Items:Specifications
Imaging sensor:CMOS
Total pixels:640 x 480
View angle:42º
Minimum illumination:0Lux (LED on)
Power supply:4×AA batteries
Tube diameter:8mm
Waterproof capacity:IP67 (Only for imager head)
LCD screen type:2.8" TFT-LCD
LCD screen effective pixels:640×480
Video system：PAL/NTSC
Consumption 238±5mA/6V (Max)
Operating temperature：-10OC~50OC/14OF~122OF
Operating humidity:15~85%RH (Max.)
Accessories:magnetic tip, mirror tip, hook and rubber ring
Product Size:320×204×64mm
Packing Size:5pcs/carton, 340*335*225mm
Weight(kg):8kg
